Scythe USB Foot Switch II
* Only have Dual Pedal model in stock.
This second version of Scythe's mouse and keyboard operating USB Foot Switch has improved noise reduction, shorter key stroke and is available in one, two or three pedals. The USB Foot Switch 2 is compatible with Windows OS XP/Vista/7/8/10. Once set up on a Windows OS using the supplied software, USB Foot Switch II can be used on Mac and Linux operating systems.
The second version of mouse and keyboard operating USB Foot Switch. Optical instead of mechanical switch. Friction noise highly reduced with rubber. The USB Foot Switch 2 provides a 3 mm shorter key stroke allowing less force for switching. USB Foot Switch 2 is available in one, two or three-button and can be freely assigned by the operating software.
Scythe USB Foot Switch II Features
Improvements compared to first version:
1) Noise reduction
Better noise behavior. The reasons for the noise in the first version were the mechanical switch, which was changed to an optical switch and a friction sound coming from the metal cover, which could be strongly reduced by attaching rubber. Altogether noise has been highly improved for the USB Foot Switch 2.
2) Shorter key stroke
Instead of an 8mm key stroke the new Foot Switch 2 has an shorter, 5mm key stroke. Therefore less pressure (power) is needed to handle the switch. Less fatiguing, especially in case of frequent, repeated use.
3) USB
Only requires a USB interface. No drivers are required, the footswitch is recognized as a USB HID in the OS. The enclosed software is only required to define the emulated keys. Left and right mouse clicks, double clicks, all keyboard keys and all ctrl / alt shortcuts can be integrated. The configured foot switch can then be used on other PCs without any additional software or settings.
| Scythe USB Foot Switch Specifications | |
|---|---|
| Model Name: | USB Foot Switch 2 Single USB Foot Switch 2 Double USB Foot Switch 2 Triple |
| Model Number: | USB-1FS-2 USB-2FS-2 USB-3FS-2 |
| Weight: | 230 g / 7.423 oz. (Single) 570 g / 20.10 oz. (Double) 900 g / 31.75 oz. (Triple) |
| Dimensions Overall: | 120 x 67 x 34 mm / 4.72 x 2.64 x 1.34 in (Single) 130 x 210 x 37 mm / 5.11 x 8.26 x 1.46 in (Double) 130 x 360 x 37 mm / 5.11 x14.17x 1.46 in (Triple) |
| Dimensions Switch: | 120 x 67 x 34 mm / 4.72 x 2.64 x 1.34 in (Single) 120 x 67 x 34 mm / 4.72 x 2.64 x 1.34 in (Double) 120 x 67 x 34 mm / 4.72 x 2.64 x 1.34 in (Triple) |
| Cable Length: | approx. 180 cm / 70.87 in |
| Key Stroke: | approx. 5 mm / 0.1969 in |
| Compatible OS: | Windows XP/VISTA/7/8/10 |
| Driver Download | USB Foot Switch II Software |
